Type MPan – Pan Lid Drainage Frame

MSU MPan hatches are designed to match the adjacent flooring or surface. The MPan’s lid accommodates flooring materials in a range of thicknesses and is suitable for interior and exterior areas subjected to pedestrian loads.

Safety controls are engineered right into all MSU access hatches.

MPan access hatches are:

  • Aluminum construction
  • Gasketed drainage frame
  • Welded drain coupling and ABS fittings
  • Pan lid has a variable depth from 6 to 25mm
  • Hold open arm, in type 316 stainless steel, locks lid safely at 90 degree vertical
  • Continuous hinges in 316 stainless steel
  • Lifting spring in 316 stainless steel
  • Slam lock in type 316 stainless steel with sealing plug and opener
  • Recessed padlock hasp ( padlock by others)
  • Reinforced for 14.4 kPa pedestrian loading
  • Cast anchors
  • Bituminous paint on all areas in contact with concrete
  • All fasteners in stainless steel type 316
  • Perimeter anchor flange
  • Welding to CSA W47.2

MSU MPan hatches are manufactured in single and double door units.

TYPE MPAN ALUMINUM HATCHES DOWNLOAD
MPan Single Door Unit 900 x 900
MPan Double Door Unit



**Sizes shown are examples only**

Options:

  • Insulation with backpan (Styrofoam sm 50mm standard)
